• Maxi Blue Drainstick Condensate Pump

Maxi Blue Drainstick Condensate Pump

SKU: GMP93

Detailed description

The Maxi Blue Drainstick Condensate Pump is small but powerful; running on Charles Austen's Rotary Diaphragm patented technology.  The pump is designed to sense when drainage water is present, so it is a energy efficient solution in a very high humidity environment where other pumps would run full time.  The design also allows the Maxi Blue to be mounted at any orientation and it does not vibrate at all so it is exceptionally quiet.  This makes it perfect for installations in offices or any other areas where low noise levels are important.  The BlueDiamond patented DrainStik is a slim line probe, which houses the water sensors and high level alarm; it can be directly mounted into the drain tube.


  • Whisper quiet
  • Patented rotary diaphragm technology
  • No maintenance required
  • Positive displacement pump eliminates need for check valve and siphon
  • Tolerates suspended solids
  • Capable of running dry without an overheating failure
  • Plenum rated and UL listed

Manufacturer

Blue Diamond

Model

Maxi Blue - DrainStik

Max Head

8mt

Max Lift

8mt

Max Flow

14ltr/hour

Conn-Int Diameter

1/4”

Specifications

Maxi Blue Drainstick Condensate Pump

Data Sheet
