Aspen Mini Blanc Pump
Aspen Mini Blanc Pump
The Aspen Mini Blanc™ (FP3578) is a stylish and powerful condensate removal pump designed to deliver neat, professional installations where appearance matters. Mounted directly beneath wall-mounted indoor units, it is an ideal solution for retrofit projects and applications where pipework and accessories need to remain discreet.
Combining reliable performance with easy maintenance access, the Mini Blanc features a removable reservoir, quiet operation, and an elegant casing that blends seamlessly with modern air conditioning installations. Capable of handling systems up to 26kW (90,000 Btu/h), it is suitable for a wide range of domestic and commercial high-wall split systems.
With a maximum flow rate of 20 L/h and a recommended maximum head of 10 metres, the Mini Blanc provides dependable condensate removal while maintaining a low operating noise level of just 19 dB(A).
| Specification | Detail |
|---|---|
| Part Number | FP3578 |
| Product Name | Aspen Mini Blanc™ |
| Pump Type | Condensate removal pump |
| Max Flow Rate | 20 L/h @ 0m head |
| Max Recommended Head | 10 m |
| Noise Level | 19 dB(A) @ 1m |
| Power Supply | 100-250 VAC, 50/60Hz |
| Power Consumption | 5W |
| Maximum Unit Capacity | 26kW (90,000 Btu/h) |
| Maximum Water Temperature | 40°C |
| Inlet / Outlet | 20mm inlet / 6mm outlet |
| IP Rating | IP24 |
| Safety Switch | 5A Normally Closed |
| Self Priming | Yes |
| Dimensions | 290 x 65 x 50 mm |
| Weight | 0.48 kg |
| Suitable For | High wall split systems |
