STÖRNCH 1.7Ltr High Flow Tank Pump
STÖRNCH 1.7Ltr High Flow Tank Pump
The pump is designed to collect condensate water from air conditioning machines and discharge it up to recommended maximum 5 metres head. The internal safety float is a low current switch to stop the air conditioning system in the event of pump failure. The pump is operated from an internal float switch.
Technical Specification:
• Non-return valve
• 2 metre connecting cable
• Tank holds 1.7 litres
• Maximum 5 metres discharge head
• Maximum water pumping capacity 300 L/h
• 1/4" & 3/8" Hose connection
• Pump has a pre-wired safety switch
• Safety switch: 3A maximum
• Pump rating 0.8A, 230 VAC
• Max. water temp: 40ºC/104ºF
• pH: Neutral
• Noise level: 49 dB(A) @ 1m
• c/w Wall Mounts
• 4 inlets
• Retaining clip for outlet barb
• Quick release reservoir
Dimensions:
Height: 138mm Width: 285mm
Depth: 144mm Weight: 1.65kg
