STÖRNCH 1.7Ltr High Flow Tank Pump
Detailed description
The pump is designed to collect condensate water from air conditioning machines and discharge it up to recommended maximum 5 metres head. The internal safety float is a low current switch to stop the air conditioning system in the event of pump failure. The pump is operated from an internal float switch.
Specifications
Technical Specification:
• Non-return valve
• 2 metre connecting cable
• Tank holds 1.7 litres
• Maximum 5 metres discharge head
• Maximum water pumping capacity 300 L/h
• 1/4" & 3/8" Hose connection
• Pump has a pre-wired safety switch
• Safety switch: 3A maximum
• Pump rating 0.8A, 230 VAC
• Max. water temp: 40ºC/104ºF
• pH: Neutral
• Noise level: 49 dB(A) @ 1m
• c/w Wall Mounts
• 4 inlets
• Retaining clip for outlet barb
• Quick release reservoir
Dimensions:
Height: 138mm Width: 285mm
Depth: 144mm Weight: 1.65kg
