• STÖRNCH 6 x 50mm Concrete Screw (pk 100)

STÖRNCH 6 x 50mm Concrete Screw (pk 100)

SKU: GMFX110-100

Detailed description

A hex flange head self tapping anchor which cuts it's own thread in the base material. Suitable for use in solid concrete, hollow concrete, bricks, dense blocks and most natural stone. • Position fixture and drill 5.0mm hole to correct depth • Blow out dust and debris from the hole • Insert anchor through fixture into concrete and tighten to the recommended torque • 8mm Hex Head

Shallow Embedment

Deep Embedment

Drill Diam

Thread Diam

Anchor Length

Fixture Clearance Hole

Maximum Fixture Thickness

Minimum Hole Depth

Maximum Fixture Thickness

Minimum Hole Depth

Head A/F

Tightening Torque

5mm

6mm

50mm

8mm

25mm

35mm

13mm

50mm

8mm

15Nm

Data Sheet
