STÖRNCH M8/M10 x 55 Concrete screw stud hanger - dual tapped (pk 100)

SKU: GMFX104-100

Detailed description

Concrete stud hangers are ideal anchor fixings for securing threaded rods and brackets to suspend HVAC conduits and ducting, sprinklers and cable trays, pipe-work or other indoor plumbing and electrical service installations.

Designed for fast secure fitting, a concrete screw stud hanger can be rapidly driven into drill holes in overhead concrete slabs or beams with a comfortably low installation torque, using an impact wrench or ordinary hammer drill. The thread automatically cuts a secure locking trajectory into the concrete.

On the hanger end, the dual tapping means it can be used for both M8 and M10 studding making it very versatile.

Load capacity necessarily depends on the concrete base material but is normally well in excess of 200 lbs per hanger.

Although securely anchored, the concrete screws can be removed again later if required, making these concrete hangers ideal for both permanent and temporary fixings. (Note, however, that drill holes and hangers should not be re-used multiple times).

Our products are always of the highest quality and the cutting edges and points of these hangers are made from corrosion resistant zinc-plated steel, heat treated to increase their cutting power and tip hardness.

  • Setting and installation in one working operation saves time
  • Completely removable therefore suitable for temporary fixings
  • Serrations on the thread makes the screws easy to screw in
  • Re-usability of the screws reduces costs

Supplied in box of 100

Specifications

M8/M10 x 55 Concrete screw stud hanger - dual tapped (pk 100)

Drill hole diameter 6mm

Spanner size 13mm hex

Min. drill hole depth for pre-positioned installation 45mm

Projection length 26.5mm
