Aspen S+ Mini Orange Gen 5 Pump
Detailed description
THE NEW SILENT+ MINI ORANGE
The world’s No.1 Orange Mini Pump is perfect for ducted units; floor standing & chassis units; high wall split systems. Ideally installed within a ceiling void or similar area. Using our proven 5th Gen Technology, the Silent+ Mini Orange boasts sound levels as low as 16dB(A)*. So quiet it eliminates the need for additional noise or vibration dampers. Capacitance sensor technology, provides intelligent, adaptive flow rates. Quietly Brilliant.
Ultra quiet – as low as 16dB(A)*
Variable speed, on demand power, unique sophisticated pump control algorithm = silence. No need for acoustic dampers, or anti-vibration mounting kits.
Proven 5th Gen Technology
Capacitance Sensing & Rotary Diaphragm = Silence & Power – up to 35L/h flow rate!
Low maintenance
Adaptive flow rates and on demand power means less stress on components.
Plug & Play**
Perfect for rapid replacement of the pump.
* Assuming solid wall construction with a 2kW unit
** New pumps are not backwards compatible with previous / current models.
Specifications
Max. flow: 35L/h @ 0m head
Max. rec. head: 10m
Max. suction lift: 1.5m
Min. dB(A) @ 1m: 16dB(A)*
Power supply: 100-250VAC, 0.18A, 2.4W,50/60 Hz
Rated: Continuous
Max. unit output: 40kW (136,000Btu/h)
Max. ambient temp: 40°C (104°F)
IP Protection: IP24
Inlet o/d: Ø16mm (5/8”)
Outlet o/d: Ø6mm (1/4”)
Safety switch: 5.0 A Normally closed
Self priming: Yes
In the box: Silent+ Mini Orange 5th Gen pump • Reservoir (inc. filter and lid) • 1.5m plug and play cable** • 1.5m clear PVC tube • 150mm clear vent hose • 220mm Orange inlet hose • Drain connector kit: straight connector and rubber elbow • Quick start guide
