Aspen Low Profile ERRP Top Inlet Refrigeration Cabinet Pump
SKU: GMP298
Detailed description
The Aspen Compact 4L ERRP (Economical Retail Refrigeration Pump) Top Inlet Refrigeration Cabinet Pump is designed exclusively to fit underneath retail refrigeration cabinets and this lightweight plastic product will pump away defrost and contaminated water at 190ltr/hour.
- Top inlet
- Low voltage at point of use
- 2-stage filter to prevent growth and spread of biofilm
- Plug & play
Manufacturer | Aspen |
Model | Compact 4L ERRP |
Tank Size | 4.2ltr |
Max Head | 35mt |
Max Flow | 190ltr/hour @ 0 head |
Size | 530mm x 242mm x 75mm |
Safety Switch | 3A NC/NO |
Specifications
Sound level @ 1m: 60 dB(A)
Power supply input: 100-240V AC 50/60Hz
Rated: Non continuous
Class: II appliance
Max. ambient temp.: 40°C / 104°F
Inlet/Outlet: 40mm in, 10mm (3/8") out
IP Protection: IPX4
Weight: 2.82kg
Included in the box:
Low Profile ERRP pump
2m Plug & Play power cable
11/2” BSP connector (for 40mm ID waste pipe)
Install manual
Data Sheet
