Hydron Dairy Pump
SKU: GMP36
Detailed description
The HY/DP30-S is a low profile, yet powerful, piston pump designed for use with dairy case installations. It’s ultra low height also means that it can be used for dairy cases where height is a restriction. It has
been designed for when low gravity drain is not available.
Made in Britain
Specifications
Input Voltage: 230V 50Hz +/-10%
Pumping Head: 30 metres
Max Flow Rate: 110ltr/hr
Tank Capacity: 5ltr
Ambient Temperature: 0-50°C
Power Consumption: 37W
Dimensions: 465 x 205 x 60mm (L x W x D)
Inlet connection: 12.7mm OD
Outlet connection: 15mm ID
Built-in check valve
Data Sheet
