Siccom Flowatch Design Pump
Detailed description
In-duct pump for air conditioners up to 10 kW / 36 000 BTU The clean lines of the FLOWATCH® DESIGN means it will easily fit into any residential or commercial installation. Quick and easy to fix: - Reversible left/right fixing plate - Delivered pre-assembled - Step-by-step installation manual - Spacious elbow: easy fitting of refrigerant pipes 3/8 & 5/8 Smart design: - Invisible fastening clips - White Duct can be cut as you need - Rubber finishing gasket The FLOWATCH® DESIGN is pre-assembled inside its box. An illustrated installation leaflet shows you how to install the kit in just a few minutes.
Specifications
Product specifications: - Low noise level pump: 20.2 dBA (certified by LNE, an independent french laboratory) - A vibration absorber belt, reducing even more the noise level - IP 64: protected from water and dust ingress Max flowrate: 15 l/h Max discharge head: 10 m Electrical power: 19 W Voltage: 220-240 V 50/60 Hz Alarm: NO-NC 5A max resistive contact Thermal protection: Yes Operating cycle* 100 % Dimensions Length: 800 mm Width: 80 mm Depth: 55 mm *The pump is able to run 100% of the time is necessary In the box: Duct with elbow • Finishing Gasket • Finishing ceiling plate • mini FLOWATCH® 2 pump in absorber bracket • Reservoir with air vent tube • power/alarm cable • Inlet & suction tube • Installation manual
