• Sauermann Si -30 Pump

Sauermann Si -30 Pump

SKU: GMP72

Detailed description

The high performance Si-30 is suitable for air-conditioning units up to 20 kW.
The piston technology is specifically designed for removing condensates from air conditioning systems. The Si-30 is fully reliable, in any kind of environment. Its operating sound level will remain silent whatever the volume of condensates.

• Increased performance: Only one pump, for air conditioning unit up to 20 kW.
• High resistance to pollution created by general environment. Capable of discharging small particles.
• Proven Reliability.
• The Drain Safe Device retains prime and prolongs the pump life.
• Improved performance and high flow rate reduce operation time and energy consumption.
• Quiet in operation: 20 dBA independently tested.
• The size of the air-conditioning unit and volume of condensates to be removed does not affect the operational sound level of the pump.
• Mounting bracket specifically designed to reduce vibration transmission to the wall / panel or pipework.
• Compact design.
• Mounting bracket: allows the pump to be wall mounted or hung from ceilings and pipework.
• Lockable plug-in power cord to avoid unintended disconnection.

Specifications

Kit Contents
• Piston pump
• Clear PVC tube Ø int. 6 mm – L: 1m, fitted with a ‘‘Drain Safe Device’’ pre-mounted
• Anti-vibration mounting bracket
• 1.5 m lockable plug-in power cable: 2 power wires, 2 safety switch wires
• 6 tie wraps, 2.5 x 100 mm
• Detection unit (SI2958, 1.5 m cable)
• Detection unit installation kit:
- Rubber elbow 90° Ø int.15 x L 60 mm
- Vent tube Ø int 4 x L 75 mm
- Mounting rail
- Adhesive

Max. flow rate: 20l/h
Max. suction head: 3m
Max. discharge head: 10m (flow rate = 4l/h)
Max. pressure: 14m (flow rate = 0l/h)
Sound level at 1m: According to EN ISO 3744 (Measured at LNE lab, pump operating with water, out of application): 20 dBa
Mains supply: 230 V~ 50/60 Hz - 14 W
Insulation class: double insulation
Detection levels: ON: 16mm; OFF: 11 mm; Safety: 19mm
Safety switch: NC 8 A resistive – 250 V
Thermal protection (overheating): 115 °C (auto-reset)
Max. condensate temperature: 35 °C
Operating conditions: 100% - Continuous duty
Protection: IP20
Safety standards: CE & EAC
RoHS directive: Compliant
WEEE directive: Compliant
