Sauermann Peristaltic Pump PE5100 T° Sensor
Detailed description
Peristaltic pumps* help lift charged condensates. Among the most compact on the market, they combine silence with a practical and clever design : detachable and replaceable head and tube = optimised maintenance and cost.
The PE5100 operates by detecting a 6°C temperature change via two temperature probes located in the air on and air off position. * These pumps must not operate continuously
Specifications
Max flow rate: 6 l/h
Max discharge head: 12m
Max suction head: 2m
Protection: IP65
Detection: Temperature differential
Pump dimensions:
Length 109mm
Width: 110mm
Height: 91mm
Sound levels at 1m in application: 30 dBA
Contents:
- Peristaltic pump PE 5100
- Cable: 1.7 m, including 2 wires for power supply (P&N).
- 2 thermal probes with 3.5m cable
- Red cap for ambient air.
- Blue cap for fresh air.
- Easy "1 screw" sliding plastic bracket
- Ø 15 mm to Ø 6 mm adaptor + pale yellow rubber (Ø 15 x 35mm) - (PE5003)
