Big Foot H-frame 330mm B6088/B

SKU: GMCG7

Detailed description

Please note - channel not included

Pack Includes: 2 Big Feet, Brackets and Fixings

The Big Foot H-frame (B6088/B) is a non-penetrative support for pipework, duct and cable ladder/tray.

The H Frame Set is a quick, versatile and economical solution for supporting pipework, duct, cable trays or any combination of these. You provide your own strut, keeping the duct and pipe installations low cost and totally flexible by fabricating the frameworks on-site.

• 50% Higher Coefficient of Friction; better surface to surface grip than rubber feet.
• Maximum stability; EPDM mat conforms better to uneven surfaces than rubber.
• Optimum weight distribution over whole foot print.
• Fits 21 × 41mm, 40 × 38mm, 41 × 41mm strut.
• Strut fittings & bolts included.
• 100% recycled glass filled nylon foot construction.

The majority of installations require 305mm (12") H Frames but where a greater load spread is required 400mm H Frames are also available.

Specifications

Big Foot H-frame 330mm

Please note - channel not included

  • Max load 300kg
  • Versatile Application
  • Quick & easy installation
  • Excellent load distribution
  • Interchangeable with 3 strut sizes - one foot fits all
  • Boxed for convenience
