Aspen Ultra Black Air Peristaltic Pump With Temperature Sensor (FP3390)
Aspen Ultra Black Air Peristaltic Pump With Temperature Sensor (FP3390)
The Aspen Ultra Black Air (FP3390) is a high‑performance peristaltic condensate removal pump designed for quiet, reliable operation in demanding HVAC installations. Built with advanced stepper motor technology and software control, it allows user‑configurable motor speed, helping to minimise noise levels and reduce tube wear over time.
Delivering up to 15 L/h flow with a 12 m head, the Ultra Black Air is ideal for a wide range of applications including high wall split systems, ducted units, floor standing and chassis units. Its flexible installation capability and strong lift performance make it particularly suited to remote or noise‑sensitive locations such as hotel bedrooms.
With simple installation via a patented mounting system, the FP3390 offers dependable long‑term performance for professional HVAC engineers.
| Specification | Detail |
|---|---|
| Part Number | FP3390 |
| Product Type | Peristaltic condensate removal pump |
| Max Flow Rate | 15 L/h |
| Max Head | 12 m |
| Max Suction Lift | 3 m |
| Noise Level | 21 dB(A) @ 1 m |
| Power Supply | 110–230 VAC, 50/60Hz |
| Max Unit Capacity | 20 kW (68,000 Btu/h) |
| Inlet / Outlet | 6 mm ID |
| IP Rating | IP24 |
| Safety Switch | 5A NC relay |
| Operating Mode | Continuous duty |
| Special Features | Configurable motor speed, self‑priming, low noise operation |
