150mm Steel In-Line Fan
SKU: GMSI150
Detailed description
The Steel Centrifugal In-Line Fans are manufactured from high grade corrosion-resistant pressed galvanised steel and are supplied complete with a pre-wired junction box. The motors are IP44 rated and all models are speed controllable.
- Motor Power Watts: 120
- Current Amps: 0.53
- Transformer Speed Controller: GMTSC15
- Electronic Speed Controller: GMESA1
Volume air flow m3/sec against static pressure pa. | |
0 | 0.208 |
50 | 0.191 |
100 | 0.173 |
150 | 0.152 |
200 | 0.130 |
250 | 0.109 |
300 | 0.088 |
400 | 0.052 |
Specifications
150mm Steel In-Line Fan c/w mounting foot
