150mm Mixed Flow In-Line Fan

This Fan is part of our range of low profile in-line mixed flow duct fans manufactured in tough reinforced plastic. The unique design of the support bracket allows the motor and impeller assembly to be fitted or removed without dismantling the adjacent ducting.

The motor is rated to Class B, with ball bearings and safety thermal overload protection. IP44.  Direct 3-speed suitable for voltage speed control.  Electrical supply: Single phase 230V-50Hz.

• Impact resistant polymer with inlet & outlet spigots
• Motor with ‘sealed for life’ bearings
• Speed controllable
• Maximum Absorbed Power:  53W
• Maximum Absorbed Current: 0.21A
• Transformer Speed Controller: GMTSC15
• Electronic Speed Controller:  GMESA1
