125mm Mixed Flow In-Line Fan
Detailed description
In-line duct fan entirely made of robust and highly-resistant polypropylene. They are particularly suited to installations where space is limited, such as false ceilings. Highly versatile, they can offer the most effective solution for a wide range of residential or commercial ventilation applications.
Benefits:
- High efficiency resulting in minimum energy costs.
- Quiet running thanks to optimized aerodynamics and guide vanes.
- Easy installation: pre-installed mounting brackets and external connection box.
- Simplified maintenance by loosening the clamps (no need to handle the duct).
- Versatile installation.
Specifications
Features:
- Duct fans, made entirely of polypropylene.
- For direct installation between ducts.
- Easy inspection and maintenance by simply opening the clamp and removing the fan.
- Helicocentrifugal mixed flow impeller with downstream stator. Made in ABS.
- Externally fitted terminal box with cable entry grommet.
Motor:
- Asynchronous motor, 2 speed
- IP 44 Protection, Motor Class B.
- Robust motor with ball bearings, maintenance-free.
- 220 - 240 at 50 Hz.
- Thermal overload protection as a standard feature.
