Blue Pre-insulated Barrier Pipe 25mm x 50m with 13mm Insulation
Detailed description
Want to save even more time and effort? Choose Pre-insulated Barrier Pipe for your Hybrid installs.
You get the best of both worlds with this blue pre-insulated 25mm Ø hybrid Barrier Pipe. Combining the benefits of both plastic and metal, the multi-layer pipe has aluminium at the core, along with inner and outer layers of tough high temperature-resistant polyethylene. Simple, safe and fast pipe installation in seconds, with no welding or soldering. And the added bonus of tough 13mm (wall thickness) insulation.
Plus we stock all the fittings, insulation and tools you're going to need for your Barrier Press Fit system install.
More info and resources
Everybody wants a leak-free hybrid job. So to make sure you follow the correct system installation procedures, head over to our specialist Hybrid Hub. You'll find loads of technical and training resources, plus pretty much everything you need to know about Hybrid and Pressfit: www.pressfitsolutions.com
Specifications
- BENEFITS
- 25mm Ø Outside 20mm Ø Inside
- Absolutely oxygen diffusion tight, multi-layer composite pipe.
- Easy handling.
- Low weight.
- High inherent stability and bend flexibility.
- Low linear expansion.
- Excellent hydrostatic stress performance.
- Corrosion resistance.
- PROPERTIES
- Same strength as metal pipe, easy to bend and reluctant to return to its former shape.
- High temperature, high pressure, and corrosion resistant.
- Smooth inner surface of the pipe reduces resistance to fluids. The ability to conduct water is 30% more efficient.
- Good property of heat preservation, heat conduction coefficient is 0.45/m.k.
- Easy to cut and install.
- Life span of more than 50 years.
Data Sheet
