STÖRNCH M10 x 55mm Rubber Ankernut (pk 25)
SKU: GMFX9-25
Detailed description
Vibration resistant fixing that can be used in virtually any construction material as the sleeve compresses in irregular holes.
Specifications
Rubber nuts - with brass threaded inserts
Thread size: M10
Hole diameter: 20mm
Wall thickness:25.0-35.0mm
Overall Length: 55mm
Flange thickness: 1.3mm
Flange diameter: 22.5mm
Recommended tightening torque: 10.0Nm
Quantity per pack: 25
Data Sheet
