315mm Steel In-Line Fan
SKU: GMSI315
Detailed description
The Steel Centrifugal In-Line Fans are manufactured from high grade corrosion-resistant pressed galvanised steel and are supplied complete with a pre-wired junction box. The motors are IP44 rated and all models are speed controllable.
- Motor Power Watts: 315
- Current Amps: 1.30
- Transformer Speed Controller: GMTSC15
- Electronic Speed Controller: GMESA3
Volume air flow m3/sec against static pressure pa. | |
0 | 0.379 |
50 | 0.356 |
100 | 0.335 |
150 | 0.317 |
200 | 0.300 |
250 | 0.280 |
300 | 0.259 |
400 | 0.215 |
450 | 0.189 |
500 | 0.163 |
600 | 0.105 |
700 | 0.017 |
Specifications
315mm Steel In-Line Fan c/w mounting foot
Data Sheet
