28mm Copper Press Fit Lever Ball Valve (pk 1)
SKU: GMCP43
Detailed description
These press fit ball valves are used for isolating pipework. Supplied with a lever and 28mm copper press fit ends, the Geberit Mapress Copper fittings are easy to press, giving you a quick and reliable install without soldering. For crimping use an 28mm M profile jaw.
More info and resources
Everybody wants a leak-free job. So to make sure you follow the correct system installation procedures, head over to our specialist Hybrid Hub. You'll find loads of technical and training resources, plus pretty much everything you need to know about Hybrid and Pressfit: www.pressfitsolutions.com
Specifications
- Conforms with BS EN 1057
- Fitted with EPDM seals (O-rings)
- Max working pressure: 16 bar (PN16)
- Working temperature range: -10°C to 110°C
- Press profile: M
- Supplied as singles
