250mm Steel In-Line Fan
SKU: GMSI250
Detailed description
The Steel Centrifugal In-Line Fans are manufactured from high grade corrosion-resistant pressed galvanised steel and are supplied complete with a pre-wired junction box. The motors are IP44 rated and all models are speed controllable.
- Motor Power Watts: 180
- Current Amps: 0.80
- Transformer Speed Controller: GMTSC15
- Electronic Speed Controller: GMESA1
Volume air flow m3/sec against static pressure pa. | |
0 | 0.287 |
50 | 0.272 |
100 | 0.256 |
150 | 0.239 |
200 | 0.221 |
250 | 0.199 |
300 | 0.178 |
400 | 0.133 |
450 | 0.109 |
500 | 0.074 |
Specifications
250mm Steel In-Line Fan c/w mounting foot
Data Sheet
