• 22mm x 22mm x ½"FT Copper Press Fit Tee (pk 10)

22mm x 22mm x ½"FT Copper Press Fit Tee (pk 10)

SKU: GMCP62

Detailed description

This Copper Press Fit Tee includes a 1/2" female threaded branch. Ideal for automatic air vents, drain off cocks and pressure gauges or manual air vents (using a brass threaded bush). The Geberit Mapress Copper fittings are easy to press, giving you a quick and reliable install without soldering. For crimping use a 22mm M profile jaw.

More info and resources
Everybody wants a leak-free job. So to make sure you follow the correct system installation procedures, head over to our specialist Hybrid Hub. You'll find loads of technical and training resources, plus pretty much everything you need to know about Hybrid and Pressfit: www.pressfitsolutions.com

Specifications

  • Conforms with BS EN 1057
  • Fitted with EPDM seals (O-rings)
  • WRAS Approved
  • Max working pressure: 16 bar (PN16)
  • Working temperature range: -10°C to 110°C
  • Press profile: M
  • Supplied in packs of 10
