  • 204 x 60mm Elbow 90° Flat Bend to 100mm Round

204 x 60mm Elbow 90° Flat Bend to 100mm Round

SKU: GMVDF30

Detailed description

204 x 60mm Elbow 90° Flat Bend to 100mm Round

NOTE: 204 x 60mm duct lengths insert into 204 x 60mm fitting.

External Dimensions

Resistance (Pa) at flow rate

H

W

D

8 l/s

13 l/s

21 l/s

29 l/s

37 l/s

45 l/s

53 l/s

61 l/s

80

215

195

2.9

7.1

15.1

28

45.1

68.1

92.2

118

Specifications

204 x 60mm Elbow 90° Flat Bend to 100mm Round
