• 100mm x 6m PVC Flexi Ducting

100mm x 6m PVC Flexi Ducting

SKU: GMVF16P

Detailed description

STÖRNCH PVC Coated Flexible Duct is the solution to many awkward vent install scenarios. Ideal for connecting rigid spiral ductwork to outlets via a plenum, or simply to an air valve - can be used for supply or return sections. The spiral of steel wire is corrosion resistant and ensures dimensional stability to obtimise the flow of air.

USES
Ideal for low to high pressure heating, ventilation and air conditioning supply or extract systems for use on both commercial and industrial applications.

CONSTRUCTION
Laminated construction encapsulating a high tensile steel wire helix ensuring there is no separation from the duct material. The duct is covered with a tough co-polymer outer vapour barrier, which acts as a unique extra-airtight, strong and durable barrier.

Specifications

Nominal Thickness: 150 micron

Diameter: 102mm

Wire Spacing: 30mm (ø > 82mm), 40mm (ø > 127mm)

Temperature Range: 30°C / +150°C

Air Velocity: 30 m/s (max)

Operating Pressure: 3000Pa (max)

Standard Length: 6mt

Packing: Single Box

Certification: BS476 Class 0

Data Sheet
