100mm Steel In-Line Fan
SKU: GMSI100
Detailed description
The Steel Centrifugal In-Line Fans are manufactured from high grade corrosion-resistant pressed galvanised steel and are supplied complete with a pre-wired junction box. The motors are IP44 rated and all models are speed controllable.
- Motor Power Watts: 75
- Current Amps: 0.33
- Transformer Speed Controller: GMTSC15
- Electronic Speed Controller: GMESA1
Volume air flow m3/sec against static pressure pa. | |
0 | 0.082 |
50 | 0.074 |
100 | 0.067 |
150 | 0.060 |
200 | 0.052 |
250 | 0.044 |
300 | 0.033 |
Specifications
100mm Steel In-Line Fan c/w mounting foot
Data Sheet
